Sammy Maximum Speed - Speaker Volume (Sound); Modem Connector (Srl) >>> Option; Dip Switch (2 Positions)

SOUND
9 6
5 1
SRL
21
SW
ON
OFF
No. I/O
1
2
3
4
5
6
7
8
9
-
IN
OUT
OUT
-
-
OUT
IN
-
N.C.
RXD2
TXD2
DTR
GND
N.C.
RTS
CTS
N.C.
ON OFF
SW-1
SW-2
15KHZ31KHZ
SPEAKER VOLUME (SOUND)
LOW
HIGH
MODEM CONNECTOR (SRL) >>> OPTION
JST 9PIN SUB, CONNECTOR (MALE)
SW-1: Change Frequency of TV signal.
Default is OFF = 15KHz*
*For Standard = Low resolution
monitor
SW-2: Change ON position to go to
SYSTEM MENU.
SYSTEM MENU
MODE
GAME
MODE
Use for adjusting game sound
FUNCTION
13
DIP SWITCH (2 POSITIONS)
