Sammy Maximum Speed - Stereo Speaker Output Connector >>> Option; VGA (31 Khz) TV SIGNAL OUTPUT CONNECTOR (VDO) >>> OPTION

CN3
10
9
1
2
VDO
11
6
10
15
1
5
No. I/O
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
OUT
OUT
OUT
-
-
-
-
-
OUT
-
-
-
OUT
-
-
R
G
B
N.C.
GND
R-GND
G-GND
B-GND
+5V
GND
N.C.
N.C.
COMP SYNC
N.C.
N.C.
No. I/O
1
3
5
7
9
OUT
OUT
OUT
OUT
-
STEREO SPEAKER L
+
STEREO SPEAKER L
-
STEREO SPEAKER R
+
STEREO SPEAKER R
-
N.C.
No. I/O
2
4
6
8
10
OUT
IN
-
OUT
-
TXD
RXD
GND
+5V
N.C.
14
STEREO SPEAKER OUTPUT CONNECTOR >>> OPTION
Cannot use JAMMA speaker output & STEREO speaker output at same time.
NOTE:
STEREO SPEAKER OUTPUT & EXTENSION SERIAL CONNECTOR, PIN LAYOUT
(JST, 10 PIN PHD CONNECTOR)
FUNCTION
FUNCTION
VGA (31KHz) TV SIGNAL OUTPUT CONNECTOR (VDO) >>> OPTION
Use this connector when TV Monitor
is High Resolution.Make sure DIPSW #1
is set to ON position.
VGA OUTPUT CONNECTOR, PIN LAYOUT
(JST, 15 PIN D-SUB CONNECTOR, 3 SEQUENCE, FEMALE)
FUNCTION
