Samson 5006-0 - 10 Dimensions in MM

10 Dimensions in mm
3054
158 17
30
245.5
121114.5
145.8 58
60
31
194
180.5
32.5148
25.5
43
80
117
158.5 72
M8
141.5
80
37
A
B
0
20
40
60
80
100
%
m
3
Two bore holes ø 8.5 mm for attach-
ment to measuring chamber rear side
to fit M8 screws
Two bore holes ø 8.5 mm for
attachment to the valve block
Control panel
Pressure gauge acc.
to manufacturer
Pressure sensor acc.
to manufacturer
Pressure gauge connections:
For pressure gauge NG 100:
male thread G1/2 B-LH with coupling sleeve G1/2
DIN 16 283 and O-ring 12x2
For pressure gauge NG 63:
female thread G1/4 with seal
EB 9527-1 EN
29
Dimensions in mm
