Auro D12/D1510
D12 D15
Output Power
RMS Power 400 W @ 8 ohms
Peak Power
800 W @ 8 ohms
Nominal Impedance 8 ohms
Transducers
Low Frequency 12” bass transducer,
2.5” voice coil
15” bass transducer,
3” voice coil
High Frequency 1.34” (34 mm) compression driver
Acoustic Performance
Frequency Response (-10 dB) 60 Hz - 20 kHz 50 Hz - 20 kHz
Sensitivity (1W @ 1m) 94 dB 95 dB
Maximum Sound Pressure Level 118 dB SPL @ 1 m 120 dB SPL @ 1 m
Horizontal Coverage Angle 90°
Vertical Coverage Angle 60°
Crossover
Crossover Type 12 dB/oct Linkwitz-Riley
Crossover Frequency 3.5 kHz
Inputs
Inputs Speakon® & ¼” Parallel Inputs
Dimensions and Weight
Dimensions Length 14”/356 mm 17.75”/450 mm
Width 10.8”/275 mm 13.5”/342 mm
Height 21.5”/546 mm 27.5”/698 mm
Weight lbs 28.5 lbs/12.95 kgs 39 lbs/17.7 kgs
Mounting
Mounting Method Integral 1 3/8” Pole Mount Receptacle
Fly Point 1
Specications
Specications are subject to change without notice.
