Controls and Functions
Setting Up Your dB500 System
Using Speaker Stands
The dB500 enclosure features a standard 1 3/8”,
pole mount receptacle, which are compatible with
speaker stands from a variety of manufacturers.
Before installing the dB500 on a speaker stand,
loosen the thumbscrew located on the bottom of the
rear side of the enclosure. Once installed on the
stand, be sure to tighten the thumbscrew to hold the
speaker in place. Be careful not to over tighten the
thumbscrew to avoid stripping the threads.
Stacking the dB500
The dB500 enclosure incorporates gender mating
stack feet and bumpers that allows you to stack one
dB500 on top of another. When stacking the
dB500’s, be certain that the rubber feet from the top
unit are securely fastened into the bottom unit’s
stacking bumpers.
NOTE:
DO NOT STACK dB500’s OVER TWO (2)
TALL.
