Specifications
L612
Inputs
Microphone
. . . . . . . . . . . .Balanced XLR
Line
. . . . . . . . . . . . . . . . . . . .Balanced XLR
Outputs
Extension
. . . . . . . . . . . . . . .Balanced XLR
Controls
Mic Level
. . . . . . . . . . . . . . . .Rotary
Line Level
. . . . . . . . . . . . . . .Rotary
Low EQ
. . . . . . . . . . . . . . . . . Rotary Center Detent, +/- 12dB @100Hz
High-EQ
. . . . . . . . . . . . . . . . Rotary Center Detent, +/- 12dB @
10kHz
Output Switch
. . . . . . . . . . Push Switch, Selects Mix or Thru for
Line Output Connector
Amplifier . . . . . . . . . . . . . . . . . . .
Low Frequency
. . . . . . . . .250 Watt RMS
High Frequency
. . . . . . . . .50 Watt RMS
Crossover Frequency
. . . .2.3 kHz,3 pole (12dB Per Octave)
Speakers
LF Driver
. . . . . . . . . . . . . . . . 12” heavy-duty bass transducer, 3”
voice coil
Impedance
. . . . . . . . .4 ohms
HF Driver
. . . . . . . . . . . . . . . 1.4” titanium compression driver, edge-
wound copper voice coil, 75 oz. mag-
net structure
Exit Throat Diameter
. . . . .1”
Frequency Response . . . . . .55 Hz – 19 kHz , +/- 5dB
Mounting
Stand
. . . . . . . . . . . . . . . . . . .Integral 1 3/8”, Pole Mount Receptacle
Weight . . . . . . . . . . . . . . . . . . . .50.11 lbs (22.78 kg)
Dimensions (H x W x D) . . . . 25.19” x 16.14” x 15.74” (640mm x
410mm x 400mm)
L615
Inputs
Microphone
. . . . . . . . . . . . .Balanced XLR
Line
. . . . . . . . . . . . . . . . . . . .Balanced XLR
Outputs
Extension
. . . . . . . . . . . . . . .Balanced XLR
Controls
Mic Level
. . . . . . . . . . . . . . .Rotary
Line Level
. . . . . . . . . . . . . . .Rotary
Low EQ
. . . . . . . . . . . . . . . . .Rotary Center Detent, +/- 12dB @100Hz
High-EQ
. . . . . . . . . . . . . . . . . Rotary Center Detent, +/- 12dB @
10kHz
Output Switch
. . . . . . . . . . Push Switch, Selects Mix or Thru for
Line Output Connector
Amplifier
Low Frequency
. . . . . . . . .250 Watt RMS
High Frequency
. . . . . . . . .50 Watt RMS
Crossover Frequency
. . . .2.3 kHz,3 pole (12dB Per Octave)
Speakers
LF Driver
. . . . . . . . . . . . . . . . 15” heavy-duty bass transducer, 3”
voice coil
Impedance
. . . . . . . . .4 ohms
HF Driver
. . . . . . . . . . . . . . . 1.4” titanium compression driver, edge-
wound copper voice coil, 75 oz. mag-
net structure
Exit Throat Diameter
1”
Frequency Response . . . . . .52 Hz – 19 kHz, +/- 5dB
Mounting
Stand
. . . . . . . . . . . . . . . . . . .Integral 1 3/8”, Pole Mount Receptacle
Weight . . . . . . . . . . . . . . . . . . . .52.47 lbs. (23.85 kg.)
Dimensions (H x W x D) . . . . 28.14” x 17.71” x 15.74” (715mm x
450mm x 400mm)
L612M
Inputs
Line
. . . . . . . . . . . . . . . . . . . .Balanced XLR
Outputs
Extension
. . . . . . . . . . . . . . .Balanced XLR
Controls
Line Level
. . . . . . . . . . . . . . .Rotary
66
612M - continued
Low EQ . . . . . . . . . . . . . . . . .Rotary Center Detent, +/- 12dB
@100Hz
High-EQ
. . . . . . . . . . . . . . . .Rotary Center Detent, +/- 12dB @
10kHz
Amplifier
Low Frequency
. . . . . . . . .250 Watt RMS
High Frequency
. . . . . . . . .50 Watt RMS
Crossover Frequency
. . . .2.3 kHz,3 pole (12dB Per Octave)
Speakers
LF Driver
. . . . . . . . . . . . . . . . 12” heavy-duty bass transducer, 3”
voice coil
Impedance
. . . . . . . . .4 ohms
HF Driver
. . . . . . . . . . . . . . . 1.4” titanium compression driver,
edge-wound copper voice coil, 75
oz. magnet structure
Exit Throat Diameter
1”
Frequency Response . . . . . .56 Hz – 19 kHz, +/- 5dB
Weight . . . . . . . . . . . . . . . . . . . .57.46 lbs. (26.12 kg.
Dimensions (H x W x D) . . . . 25.19” x 16.14” x 13.97” (640mm x
410mm x 355mm)
L1212
Inputs
Line
. . . . . . . . . . . . . . . . . . . .Balanced XLR
Outputs
Extension
. . . . . . . . . . . . . . .Balanced XLR
Controls
Line Level
. . . . . . . . . . . . . . .Rotary
Amplifier
Low Frequency
. . . . . . . . .400 Watt RMS
High Frequency
. . . . . . . . .100 Watt RMS
Frequency Response
. . . .58 Hz – 24 kHz ± 5 dB
Crossover Frequency
. . . .2.3 kHz, 3 pole (12dB Per Octave)
Speakers
LF Driver
. . . . . . . . . . . . . . . . 2x12” heavy-duty bass transducer,
2.5” voice coil
Impedance
. . . . . . . . .8 ohms
HF Driver
. . . . . . . . . . . . . . . 1.75” titanium compression driver,
edge-wound copper voice coil, 75
oz. magnet structure
Exit Throat Diameter
1”
Frequency Response . . . . . .50 Hz – 23 kHz ± 5 dB
Weight . . . . . . . . . . . . . . . . . . . .75.81 lbs (34.46 kgs)
Dimensions (H x W x D) . . . . 37.8” x 16.14” x 15.74” (960mm x
410mm x 400mm)
L1215
Input
Line Balanced
. . . . . . . . . . .Balanced XLR
Outputs
Extension
. . . . . . . . . . . . . . .Balanced XLR
Controls
Line Level
. . . . . . . . . . . . . . .Rotary
Amplifier
Low Frequency
. . . . . . . . . .400 Watt RMS
High Frequency
. . . . . . . . .100 Watt RMS
Crossover Frequency
. . . .2.3 kHz,3 pole (12dB Per Octave)
Speakers
LF Driver
. . . . . . . . . . . . . . . . 2x15” heavy-duty bass transducer,
3” voice coil
Impedance
. . . . . . . . .8 ohms
HF Driver
. . . . . . . . . . . . . . . 1.75” titanium compression driver,
edge-wound copper voice coil, 75
oz. magnet structure
Exit Throat Diameter
1”
Frequency Response . . . . . .48 Hz – 23 kHz ± 5 dB
Weight . . . . . . . . . . . . . . . . . . . .89.97 lbs. (38.17 kg.)
Dimensions (H x W x D) . . . . 43.7” x 18.89” x 15.74” (1110mm x
480mm x 400mm)
Specifications are subject to change without notice.
