MDR10 Wiring Guide
Unbalanced 1/4” Connector
XLR
Balanced Wiring Guide
CONNECTING THE MDR10
The are several ways to interface the MDR10 to support a variety of applications. The MDR10 features balanced
inputs and outputs, so connecting balanced and unbalanced signals is possible.
Balanced TRS 1/4” Connector
