4
1
3
6
4
2
5
1. Capsule - Large, 1-inch (25mm) diaphragm with
Cardioid polar pattern.
2. Windscreen - Dual stage grille protects the cap-
sule and helps reduce wind noise and p-popping.
3. LED - Three-color LED illuminates blue to indi-
cate power, amber to indicate that the micro-
phone is muted, and ashes red when the input
signal is clipping.
4. Headphone Volume - Controls the overall level
of the Meteor Mic’s headphone output.
5. Microphone Mute Button - Mutes the output of
the microphone to the computer and head-
phone output. The LED will illuminate amber
when the microphone is muted.
6. Stand Mount - Standard 5/8-inch thread mount
to attach the Meteor Mic to a microphone stand.
Meteor Mic Layout
