38
38
RS10
Power Rating (@ 8Ω): 125 Watts RMS, 220 Watts Program
Nominal Impedance: 8 Ohms
Frequency Response: 60 Hz – 20 kHz ± 3 dB
Sensitivity: 95 dB SPL @ 1W/1m
MAX SPL: 115dB
LF Driver: 10-inch heavy-duty driver
HF Driver: 1-inch exit, 44mm Mylar diaphragm
compression driver
Protection: Internal overload Lamp on HF driver
Mounting: Integral 1 3/8-inch Pole Mount Receptacle
Weight: 33.25 lbs. 15.1 kg
RS10M
Power Rating (@ 8Ω): 125 Watts RMS, 220 Watts Program
Nominal Impedance: 8 Ohms
Frequency Response: 60 Hz – 20 kHz ± 3 dB
Sensitivity: 95 dB SPL @ 1W/1m
MAX SPL: 115 dB
LF Driver: 10-inch heavy-duty driver
HF Driver: 1-inch exit, 44mm Mylar diaphragm
compression driver
Protection: Internal overload Lamp on HF driver
Mounting: 25º and 30º wedge monitor position
Weight: 31.5 lbs. 14.28 kg
RS12M
Power Rating (@ 8Ω): 175 Watts RMS, 300 Watts Program
Nominal Impedance 8 Ohms
Frequency Response: 50 Hz – 20 kHz ± 3 dB
Sensitivity: 97 dB SPL @ 1W/1m
MAX SPL: 121dB
LF Driver: 12-inch heavy-duty driver
HF Driver: 1-inch exit, 44mm Mylar diaphragm
compression driver
Protection: Internal overload Lamp on HF driver
Mounting: 25º and 30º wedge monitor position
Weight: 37 lbs. 16.7 kg
RS15M
Power Rating (@ 8Ω): 225 Watts RMS, 400 Watts Program
Nominal Impedance: 8 Ohms
Frequency Response: 40 Hz – 20 kHz ± 3 dB
Sensitivity: 98 dB SPL @ 1W/1m
MAX SPL: 126dB
LF Driver: 15-inch heavy-duty driver
HF Driver: 1-inch exit, 44mm Mylar diaphragm
compression driver
Protection: Internal overload Lamp on HF driver
Mounting: 30º wedge monitor position
Weight: 49 lbs. 22.2 kg
Specifications/Caractéristiques techniques/Technische Daten/Especificaciones técnicas/Specifiche
