RS112A RS115A
Output Power
400 Watts Peak (300 LF + 100 HF)
200 Watts RMS (150 LF + 50 HF)
Max. SPL (1M) 110dB 113dB
Frequency Response 55Hz – 20KHz 50Hz – 20kHz
Low Frequency
12” (305mm) Woofer
2” (50.8mm) Voice Coil
15” (381mm) Woofer
2.5” (63.5mm) Voice Coil
High Frequency
1” (25.4mm)
1” (25.4mm) Voice Coil
Crossover
Frequency: 3.8KHz
Type: 24dB/Oct
Horn Coverage 90°H x 60°V
Inputs Balanced XLR–1/4” Combo, USB XPD Wireless
Output Balanced XLR Line Output
Contour Equalization 100Hz & 12kHz Boost
Electro
nic Protection Thermal, Overload, Analog (Optical) Limiter, Compressor
AC Connector 3-pin IEC 250 VAC, 20 A male
Power Consumption ~AC100-120V/220-240V 50/60Hz 285W
Fuse 100-120V T6.3AL AC 250V, 220-240V T3.15AL AC250V
Enclosure Polypropylene
Grille Full metal perforated
Handles Two side, one top
Monitor Angle 45°
Mounting Method 1-38” (35mm) Pole Mount Receptacle
Dimensions
(LxWxH)
15” x 12.9” x 23.9”
380mm x 327mm x 606.5mm
15.2” x 14” x 24.9”
386mm x 356mm x 631.5mm
Weight 30.8lb / 14kg 32.6lb / 14.8kg
Specifications
11RS112A / RS115A
