17
The UR7 receiver can be installed into a standard 19” rack for transport or permanent installation using the
included rack ears.
Affix the included rack ears to each side of
the UR7 receiver. Secure the rack ears in
place using the screws provided.
Position the UR7 receiver into an available
rack space and slide in until the rack ears
are touching the rails of the rack case and
are aligned with the rack rail holes.
Mount the receiver into the rack using the
appropriate size rack screws (not included).
To ensure equal tension and balance when
installing the receiver, you should secure
screws in a crisscross pattern of opposite
corners: top left -> bottom right -> top right
-> bottom left.
A dual receiver rack mount kit (RKUR7) is
available to mount two UR7 receivers in one
rack space. The kit includes two short rack
ears, a center connection piece, and a rear
joint plate.
Rack Mounting
