This section describes the various boot modes that are supported on the ARTIK 710 Development Environment. Table 2 and
Figure 6 show how to manipulate SW4 and where SW4 is located on the Interposer Board to set the various booting options
that are available on the ARTIK 710 Development Environment.
SW4
Comment
eMMc 1st Boot
SD Card 1st Boot
USB 1st Boot
1

Off
Off
On
2

Off
Off
On
3
Hardware Board Revision ≤ 0.5
On
On
X
3
Hardware Board Revision ≥ 1.0
Off
Off
X
4

Off
On
X
