Samsung 710 - Antenna

15
When using Wi-Fi/Bluetooth (same antenna) or ZigBee the included antenna’s need to be attached to the Interposer Board,
see also Figure 11. The most important antenna properties are conveyed in Table 3.
Antenna Property
Dipole Antenna
Antenna peak gain
+1.43dB (2.4GHz)/+0.91dB (5GHz)
Frequency
2.4GHz, 5GHz (for Wi-Fi, BT, ZigBee)
Connector type
SMA-M
Antenna size
108.7mm
