The Platform board has 1x SD-CARD interface supporting SD3.0 located as can be seen in Figure 14.
The Platform board has 1x 4 pin ear jack interface supporting stereo audio as can be seen in Figure 15.
The Platform board has 1x MIPI DSI and 1x MIPI CSI interface. The location of the DSI Display interface can be seen in Figure
16. The location of the MIPI CSI interface can be seen in Figure 17.The MIPI DSI interface can operate at a maximum resolution
of WUXGA (1920x1200), whereas the MIPI CSI interface can have a static resolution of 5M pixels or a dynamic resolution for
video capturing of 1080P.
