10
Preparations
Chapter 02
Installation
Attaching the Stand
1 2
Insert the stand neck into the stand base in the
direction shown in the figure. Tightly fasten the
connecting screw at the bottom of the stand base.
Place the protective Styrofoam (cushion) included in
the package on the floor and place the product facing
down on the Styrofoam, as shown in the image. If
Styrofoam is unavailable, use a thick sitting mat.
3
4
5
Place the stand neck on the display, as shown in the figure. When you place the stand
neck, ensure that the raised button on the display can be inserted into the groove of the
stand neck.
Turn the stand neck of the display clockwise for 90°
to ensure that the stand neck of the display is put
into place. (Even if you hear a click sound, turn it 90°
clockwise for checking.)
Stand assembly is complete.
To Next Page
