Samsung 910N - Reassembly

3 Disassembly and Reassembly
3-2 MJ15AS*/MJ17AS*/MJ19AS*/
MJ15BS*/MJ17BS*/MJ19BS*
6. Remove 7 screws, 4 hexa screws from the
boards and lift up the boards.
Caution : When repairing panel only,
disconnect just LVDS cable, Panel-Lamp /
Wire marked in circle in the picture without
removing the screws on board in order to lift
the board up.
7. This picture is panel.
!
3-2 Reassembly
Reassembly procedures are in the reverse order of disassembly procedures.
