0 MJ15AS
1 E27-MJ15AS - 1 SEC,LTM150XO-L01 -
3 BN94-00527D - ASSY PCB MAIN MJ15AS SNA
4 0204-002420 CIS3 SOLVENT 1M-1000,C3H70H,96,-,- SNA
4 0204-002426 CIS4 FLUX DF-201TVS,MIX,0.820,FLUX13%,14KG,- SNA
4 3701-001219 CN101 CONNECTOR-DSUB 15P,3R,FEMALE,ANGLE,AUF SA
4 3711-004712 CN600 CONNECTOR-HEADER BOX,9P,1R,2mm,STRAIGHT,SN SA
4 6003-000117 IP/PCB+BRKT/PCB SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A SNA
4 6003-000117 M/PCB+BRKT/PCB SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A SNA
4 BN97-00354K MICOM ASSY MICOM GS17VS SA
5 0903-001347 IC200 IC-MICROCONTROLLER
NT68F63GL,8Bit,PLCC,44P,653MIL,12MHz,ST,-,PLASTIC,5.000000V,-,-0to+70C,256B,-,-,
SNA
5 BN82-00114L CIS A/S MICOM GS17VS SNA
4 BN97-00358T - ASSY SMD MJ15AS SNA
5 3301-000314 BD100 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD101 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD102 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD103 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD104 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD105 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 2703-001334 BD106 INDUCTOR-SMD 1.5uH,10%,2012 SA
5 3301-000314 BD200 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 3301-000314 BD201 BEAD-SMD 120ohm,1.6x0.8x0.8mm,150mA,,,,40000ohm SNA
5 2203-005005 C100 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C101 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C102 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C103 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C104 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C105 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-000257 C106 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 SA
5 2203-005005 C110 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C112 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C114 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-000236 C116 C-CER,CHIP 0.1NF,5%,50V,C0G,TP,1608 SA
5 2203-000998 C117 C-CER,CHIP 0.047NF,5%,50V,C0G,TP,1608 SA
5 2203-005005 C200 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005437 C201 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2203-005005 C203 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005437 C205 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2203-005065 C206 C-CER,CHIP 1000nF,+80-20%,10V,Y5V,-,1608 SA
5 2203-000257 C221 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 SA
5 2203-000257 C222 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 SA
5 2203-000189 C224 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, SA
5 2203-005005 C400 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2402-001042 C401 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm SA
5 2203-005005 C402 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C403 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C404 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C405 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C406 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C407 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C408 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C409 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C410 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C411 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C412 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C413 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C414 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C415 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-000426 C416 C-CER,CHIP 0.018NF,5%,50V,C0G,TP,1608 SA
5 2203-000257 C417 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 SA
5 2203-000426 C418 C-CER,CHIP 0.018NF,5%,50V,C0G,TP,1608 SA
5 2203-005005 C419 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C420 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C421 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2402-000108 C422 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.4 SA
MJ15AS*/MJ17AS*/MJ19AS*/
MJ15BS*/MJ17BS*/MJ19BS*
7-1
Level Loc. No. Code No. Description Specification Remarks
7 Electrical Parts List
❈ You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
7-1-1 MJ15AS* Main PCB Parts
