5 2007-000090 R600 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000090 R602 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000074 R603 R-CHIP 100ohm,5%,1/10W,TP,1608 SA
5 2007-000090 R604 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2801-003773 X400 CRYSTAL-SMD 12MHZ,30PPM,28-AAN,20PF,50OHM,TP SA
5 0403-001411 ZD100 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0403-001411 ZD101 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0403-001411 ZD102 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0403-001411 ZD103 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0403-001411 ZD104 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0403-001411 ZD200 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
7 Electrical Parts List
MJ15AS*/MJ17AS*/MJ19AS*/
MJ15BS*/MJ17BS*/MJ19BS*
7-7
Level Loc. No. Code No. Description Specification Remarks
2 BN90-00329T - ASSY STAND MJ17ASAB/*,BK07,PIVOT SNA
3 BN96-01193B STD ASSY STAND P-PIVOT Matisse17/19,ABS HB,BK07 SNA
2 BN90-00641C - ASSY COVER REAR MJ17AS SNA
3 6003-000337 C/R+STD SCREW-TAPTITE BH,+,S,M4,L10,ZPC(BLK),SWRCH18 SNA
3 BN96-01054B C/R ASSY COVER P-REAR MJ17AS,ABS HB,BK07 SNA
4 BN61-00377A C/R BRACKET-VESA GOYA19(193V),SECC,T1.0 SNA
4 BN63-01209B C/R COVER-REAR MJ17AS,ABS HB,BK07,NONE1.5 -
2 BN90-00642V - ASSY COVER FRONT MJ17ASAB,ADC,BK07,S/M711N SNA
3 6003-001086 C/F+C/R SCREW-TAPTITE BH,+,B,M3,L12,ZPC(BLK),SWRCH18A SNA
3 BN96-01056G C/F ASSY COVER P-FRONT MJ17AS (S/M 711N),ABS HB,BK07 SNA
4 BN61-01243A C/F HOLDER-PCB MJ17,ABS HB,BK07 SNA
4 BN63-01208B C/F COVER-FRONT MJ17AS,ABS HB,BK07 -
4 BN64-00288C C/F KNOB-FUNCTION MJ15/17/19,ABS,PC,BK07 SNA
4 BN67-00120A C/F LENS-LED MATISSE,ACRYL,CLEAR SA
4 BN96-01111A C/F ASSY BOARD P-FUNCTION MATISSE,FUNCTION SNA
2 BN91-00349P - ASSY LCD-E23 GY17HS SNA
3 BN07-00160A LCD LCD-PANEL
LTM170EU-L11,GOGH,6BIT,358.5*296.5*17.5,16.2M,40,0.264*0.264,0~50,5V,TN
SA
2 BN91-00784S - ASSY CHASSIS MJ17AS SA
3 BN44-00113A CIS IP BOARD
MATISSE,1.5mA~3.0mA,6.1mA~7.3mA,48kHz,4,AC90V~264VAC,5Vdc /13Vdc,0°…°≠ 32°…,50/
SNA
3 BN61-01102A CIS BRACKET-PCB MJ17AS,SECC,T1.0 SNA
2 BN91-00785D - ASSY SHIELD MJ17BS/AS SNA
3 0203-001598 CIS TAPE-FILAMENT #8915,0.15,12,55000,CLR SNA
3 BN39-00244A CIS CBF SIGNAL
BU15AO(T541A),15P/15P,20276-N,1830MM,UL20276,BLACK,D-SUB/MALE ,DET. TYPE
SA
3 BN39-00513A CIS LEAD CONNECTOR
MJ17AS(BS),UL1571#30,UL/CSA,30P,160mm,#30,1635L-30,12507HS-30L,BK,SJ03-01-638,AT
SNA
3 BN39-00523C CIS LEAD CONNECTOR
MJ17/19*,UL1061#28,UL/CSA,6P/5P,90mm,#28,12507HS-06L,12505HS-05,BK,AT TAPE
SNA
3 BN61-01234A CIS HOLDER-INVERTER MATISSE,ABS V0,BK07 SNA
3 BN64-00258A CIS PANEL-SPACER MJ17AS/BS,ABS HB,BK07 SNA
3 6003-000117 SH/COV+BRKT/PCB SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A SNA
3 6003-000276 SH/COV+C/F SCREW-TAPTITE BH,+,B,M3,L10,ZPC(YEL),SWCH10 SNA
3 6001-000559 SH/COV+PAN SCREW-MACHINE FH,+,M3,L6,ZPC(YEL),SWRCH18A,FP,- SNA
3 BN96-01059A CIS ASSY MISC P-SHIELD COVER MJ17AS/BS,SECC T1.0 SNA
4 BN63-01211A CIS SHIELD-COVER MJ17AS,SECC,T0.8 SNA
4 BN63-01313A CIS COVER-INSULATOR MJ17,19AS/BS,PET,T0.35 SA
2 BN92-00752R - ASSY LABEL GG15AS SNA
3 BN68-00614A CIS LABEL RATING-00 ALL,SS,PE,T0.05,90*45,BLK,POLYESTER,NO SILK SA
2 BN92-00936S - ASSY P/MATERIAL MJ17ASAS/*,W/W,PIVOT SNA
3 0203-001102 P/M TAPE-OPP MASKING OPP-2,T0.05,W100,L400M,CLR SNA
3 6902-000379 P/M BAG AIR HDPE,T0.2,L1800,W1000,TRP,,,PAPER SNA
3 6902-000520 P/M BAG PE
HDPE/NITRON(DOUBLE),T0.015/T0.5(DOUBLE),W700,L700,TRP,28 LANGUAGE,2-
SNA
3 6902-000604 P/M BAG WRAPPING LDPE,T0.02,W500,L10000,TRP,-,- SNA
3 6902-000609 P/M BAG ROLL LDPE,T0.05,W2400,L1000,TRP,-,- SNA
3 BH69-00457C P/M PACKING-PAD BOTTOM CY15PO,FOAM,T3.0,1320,880 SNA
Level Loc. No. Code No. Description Specification Remarks
7-2-2 MJ17AS* Others
