5 2203-005005 C114 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-000236 C116 C-CER,CHIP 0.1NF,5%,50V,C0G,TP,1608 SA
5 2203-000998 C117 C-CER,CHIP 0.047NF,5%,50V,C0G,TP,1608 SA
5 2203-005005 C200 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005437 C201 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2203-005005 C203 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005437 C205 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 SA
5 2203-005065 C206 C-CER,CHIP 1000nF,+80-20%,10V,Y5V,-,1608 SA
5 2203-000257 C221 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 SA
5 2203-000257 C222 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 SA
5 2203-000189 C224 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, SA
5 2203-005005 C400 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2402-001042 C401 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm SA
5 2203-005005 C402 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C403 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C404 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C405 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C406 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C407 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C408 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C409 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C410 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C411 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C412 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C413 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C414 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C415 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-000426 C416 C-CER,CHIP 0.018NF,5%,50V,C0G,TP,1608 SA
5 2203-000257 C417 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 SA
5 2203-000426 C418 C-CER,CHIP 0.018NF,5%,50V,C0G,TP,1608 SA
5 2203-005005 C419 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C420 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C421 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2402-000108 C422 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.4 SA
5 2203-005005 C423 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C424 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005065 C603 C-CER,CHIP 1000nF,+80-20%,10V,Y5V,-,1608 SA
5 2203-005005 C604 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005005 C605 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2203-005065 C606 C-CER,CHIP 1000nF,+80-20%,10V,Y5V,-,1608 SA
5 2402-001042 C607 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm SA
5 2203-005005 C608 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2402-001042 C609 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm SA
5 2203-005005 C610 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 SA
5 2402-001042 C611 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm SA
5 2402-001042 C612 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm SA
5 3711-005543 CN200 CONNECTOR-HEADER BOX,6P,1R,1.25mm,SMD-A,SnPb,IVR SA
5 3711-005470 CN400 CONNECTOR-HEADER BOX,30P,1R,1.25mm,SMD-A,Sn+Pb,IVR SA
5 0403-001411 D100 DIODE-ZENER -,5.49-5.73V,200MW,SOD-323,TP SA
5 0401-001056 D101 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D103 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D105 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0402-001080 D600 DIODE-RECTIFIER GF1G,400V,1A,DO,TP SA
5 3301-001145 FT600 BEAD-SMD 60ohm,4516,6000mA,TP,70ohm/45MHz,82ohm/760MHz,0.01ohm SNA
5 0406-001061 IC106 DIODE-TVS MMQA5V6T3,5.32/5.6/5.88V,24W,S SA
5 1103-001023 IC201 IC-EEPROM 24C08,1Kx8,SOP,8P,5x4mm,2.5/5.5V,0to+70C SA
5 1003-001674 IC400 IC-LCD CONTROLLER SE7889,PQFP,100P,23.45x17.45mm,-,-,TR,PLASTIC,0.3-3.6V,0to+70C,-,-,- SNA
5 0505-001772 IC600 FET-SILICON FDS9933A,P,-20V,-3.8A,0.075OHM,2W,SO-8 SA
5 1203-003209 IC601 IC-DUAL VOLTAGE REGULATOR
APL5522,SOP,8P,4.9x3.9mm,PLASTIC,3.3V/2.5V,-,0to+150C,500mA/300mA,-,TP
SA
5 BN41-00412A MP1.0 PCB MAIN MJ/GS,SILVER THROGH HOLE,2L,1.0,1.6T,118*78.2,4A SNA
5 0501-002080 Q601 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SC-59,TP,120-270 SA
5 2007-000821 R106 R-CHIP 390ohm,1%,1/10W,TP,1608 SA
5 2007-001164 R107 R-CHIP 75ohm,1%,1/10W,TP,1608 SA
5 2007-001164 R108 R-CHIP 75ohm,1%,1/10W,TP,1608 SA
5 2007-001164 R109 R-CHIP 75ohm,1%,1/10W,TP,1608 SA
5 2007-001164 R118 R-CHIP 75ohm,1%,1/10W,TP,1608 SA
5 2703-001334 R119 INDUCTOR-SMD 1.5uH,10%,2012 SA
5 2007-001164 R120 R-CHIP 75ohm,1%,1/10W,TP,1608 SA
5 2703-001334 R121 INDUCTOR-SMD 1.5uH,10%,2012 SA
5 2007-000084 R122 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 SA
5 2007-000090 R123 R-CHIP 10Kohm,5%,1/10W,TP,1608 SA
5 2007-000078 R124 R-CHIP 1Kohm,5%,1/10W,TP,1608 SA
5 2007-000113 R134 R-CHIP 33ohm,5%,1/10W,TP,1608 SA
5 2007-000113 R135 R-CHIP 33ohm,5%,1/10W,TP,1608 SA
5 2007-000113 R136 R-CHIP 33ohm,5%,1/10W,TP,1608 SA
5 2007-000113 R137 R-CHIP 33ohm,5%,1/10W,TP,1608 SA
7 Electrical Parts List
MJ15AS*/MJ17AS*/MJ19AS*/
MJ15BS*/MJ17BS*/MJ19BS*
7-9
Level Loc. No. Code No. Description Specification Remarks
To Next Page
