Samsung AC MN DKH Series Service Manual

3-2 Samsung Electronics
No Parts Procedure Remark
1 PANEL & FILTER
NORMAL TYPE
(PC1NWSK 1N
PC1NWAK 1N)
1)
Push the push button of grille and open it.
2)
Detach one clip from panel and separate the
grille from panel tilting the grille 45°.
3)
Detach filter from panel.
4)
Detach 3 cover screws.
5)
Unscrew 6 panel fixing screws from indoor
unit.(use +screw driver)
3-1 Indoor unit
䒲 1WAY CASSETTE (AC036JB1DEC Series)

Samsung AC MN DKH Series Specifications

General

Series	MN DKH Series
Power Supply	220-240V, 50Hz
Noise Level (Indoor)	19 dB to 42 dB
Operating Temperature (Cooling)	18°C to 43°C
Operating Temperature (Heating)	-15°C to 24°C
