2-4
Samsung Electronics
■
Wireless r
emote controller (MR-EC00)
Item
Descriptions
Code-No.
Q'TY
Remark
Wireless remote controller
DB93-14643K
1
Optional
Batteries for remote controller
(specification: ""AAA"" type)
4301-000121
2
Remote controller holder
DB61-06087A
1
M4×16 screw
6002-000581
2
User’s manual
DB68-04667A
1
8
10
Table of Contents
Default Chapter
2
Table of Contents
2
Precautions
4
Precautions Related to Product Safety
5
Product Specifications
7
Accessories
8
Disassembly and Reassembly
14
Indoor Unit
15
Outdoor Unit
28
Troubleshooting
45
Setting an Indoor Unit Address and Installation Option
45
The Procedure of Setting Option
46
Order for Setting Options
49
Setting an Indoor Unit Installation Option
50
Changing a Particular Option
52
Option Code for each Model
53
Items to Check before Diagnostics
54
Test Run Mode and View Mode
54
Troubleshooting for Indoor Unit
55
Changing a Particular Option
58
Option Code for each Model
59
Items to Check before Diagnostics
60
Four Directions Cassette Type
60
ECO Mode(Power Save)
62
Way Cassette Type
63
Troubleshooting for Outdoor Unit
65
Wired Remote Controller
67
Troubleshooting by Symptoms
70
Indoor Temperature Sensor (Open/Short)(E121)
70
Indoor Heat Exchanger Temperature Sensor (Open/Short) (E122)
71
Indoor FAN Error (E154)
72
Communication Error after Finishing Tracking (E202)
73
Indoor Unit Float Sensor Error (E153)
74
EEPROM Circuit Failure (E162)
75
Thermal Fuse Open Error
76
PCB Diagram and Parts List
77
Indoor Unit
77
Panel PCB
81
Outdoor Unit
82
Main Pcb
83
Reference Sheet
88
Index for Model Name
90
Refrigerating Cycle Diagramc
