Samsung AC MN KH/EU Series Service Manual

3-8 Samsung Electronics
No Parts Procedure Remark
5 EVAPORATOR 9) Take off the CASE-CONTROL from
the main frame after loosen the remaining
connector.
Caution:
When you separate the connector,
pull pressing the locking button.
3 TRAY DRAIN 1) To detach TRAY-DRAIN from the main frame,
pull the bottom of the TRAY-DRAIN towards
you.
