Samsung AC MN KH/EU Series Service Manual

Samsung Electronics 3-9
No Parts Procedure Remark
4 Evaporator 1) Detach the HOLDER PIPE.
2) Unfasten the screw at the left side.
(use + Screw Driver)
3) Unfasten the screw at the right side.
(use + Screw Driver)
4) To detach Evaporator from the main frame,
pull the bottom of the Evaporator towards
you.
