3-10
Samsung Electronics
No
Parts
Procedure
Remark
5
FAN MOTOR
&
CROSS FAN
1) Unfasten the screw. (use + Screw Driver)
2) Detach the FAN Motor case.
3) Unfasten the screw a little.
(use + Screw Driver)
4) Pull the CROSS-FAN to the left side.
18
20
