6
Installation
As soon as the air handler is received, it should be inspected for possible damage during transit. If damage is evident, the
should be made in writing. Before installing the air handler you should check the cabinet for screws or bolts which may
have loosened in transit. There are no shipping or spacer brackets which need to be removed before startup. See local
Distributor for more information. Samsung assumes no liability for freight damage. Also check to be sure all accessories
such as heater kits, and coils are available. Installation of these accessories should be accomplished before the air handler
is set in place or the connecting of the wiring, electric heat, ducts or piping.
Product Inspection
Accessories
The following accessories are supplied with the indoor unit.
Installation manual Warranty card
Selecting the installation location
Decide the installation location, with the consideration of the following conditions, under user’s approval.
Place where condensation can be drained easily.
Place that allows refrigerant pipe connection within allowable distance.
Place where indoor unit will not be exposed to direct sunlight.
Place that can keep the distance of at least 3.28 ft (1 m) between power/communication cable and any electronic
devices (depending on the circumstances, problem may occur even if you secure 3.28 ft (1 m) of distance).
DB68-11271A-02_IM_CAC Universal AHU Indoor_AA_EN_.indd 6 2022-09-15 오전 9:53:14
