Samsung AC024KNZDCH/AA - Page 46

6. Capacity Correction
Pipe Length (ft)
16.4 32.8 49.2 65.6 82.0 98.4 114.8 131.2 147.6 164.0 180.4 196.9 213.3 229.7 246.1
Level Difference (ft)
98.4 -----0.960.950.940.930.920.910.910.900.890.88
82.0 ----0.970.960.950.940.930.920.910.910.900.890.88
65.6 - - - 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
49.2 - - 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
32.8 - 0.99 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
16.4 1.00 0.99 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
0.0 1.00 0.99 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
-16.4 1.00 0.99 0.98 0.97 0.96 0.95 0.95 0.94 0.93 0.92 0.91 0.90 0.89 0.88 0.87
-32.8 - 0.98 0.98 0.97 0.96 0.95 0.94 0.93 0.93 0.92 0.91 0.90 0.89 0.87 0.85
-49.2 - - 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.90 0.89 0.88 0.86 0.84
-65.6 - - - 0.96 0.95 0.95 0.94 0.93 0.92 0.91 0.90 0.89 0.88 0.86 0.83
-82.0 ----0.950.940.930.930.920.910.900.880.870.850.81
-98.4 -----0.940.930.920.910.900.890.880.860.840.80
Heating
Pipe Length (ft)
16.4 32.8 49.2 65.6 82.0 98.4 114.8 131.2 147.6 164.0 180.4 196.9 213.3 229.7 246.1
Level Difference (ft)
98.4 -----0.960.950.940.930.920.910.910.900.890.88
82.0 ----0.970.960.950.940.930.920.910.910.900.890.88
65.6 - - - 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
49.2 - - 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
32.8 - 0.99 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
16.4 1.00 0.99 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
0.0 1.00 0.99 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
-16.4 1.00 0.99 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
-32.8 - 0.99 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
-49.2 - - 0.98 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
-65.6 - - - 0.97 0.97 0.96 0.95 0.94 0.93 0.92 0.91 0.91 0.90 0.89 0.88
-82.0 ----0.970.960.950.940.930.920.910.910.900.890.88
-98.4 -----0.960.950.940.930.920.910.910.900.890.88
Outdoor Units

;>BS8;>BMTW;>S8;>MT
<:BS8<:BMTW<:S8<:MT
<@BS8<@BMTW<@S8<@MT
Cooling
