3-21
No Parts Procedure Remark
5)loosen 3pcs screw of the cabi side left.
2 Fan & Motor 1) loosen the fan screw according the
indication and detach the fab propeller
2)Cut the cable-tie
3)disconnect the wire betwwen assy control
out and motor.
