3-23
No Parts Procedure Remark
4 Heat exchanger 1) Release the refrigerant at first
2) Looosen fixing screw on both side.
3) disaessembly the pipes in both inlet
and outlet with welding torch.
4) detach the heat exchanger.
5 Compressor
1)loosen the 3 bolts at the bottom of compres-
sor.
To Next Page
