Samsung Electronics 5-4
Exploded Views and Parts List
 Parts List
No. Code No. Description Specification
Q’TY
SA/SNA
AQV09VBCX AQV12VBCX
1 D
B90-01711F ASS’Y CABI FRONT ASS’Y, SC-94445T 1 1 SA
2 D
B63-00847A GUARD FAN HIPS, SC-90073R 1 1 SA
3 D
B90-01681E ASS’Y BASE OUT ASS’Y, SC-94445T 1 1 SA
4 D
B61-02068B ASS’Y BRACKET VALVE ASS’Y, SC-94445T 1 1 SA
5 D
B67-00397A FAN-PROPELLER AS+G/F20%, Φ400 1 1 SA
6 D
B60-30004A SCREW MACHINE M6 1 1 SA
7 D
B60-00150A SCREW SPECIAL M4 4 4 SNA
8 D
B31-00431A MOTOR FAN OUT BLDC Motor, SIC-52FV-F726-2 1 1 SA
9 D
B61-01644A BRACKET MOTOR SGCC-M 1 1 SA
10 DB97-02225D ASS’Y SUPPORT PLATE B/M SGCC-M 1 1 S
A
11 DB94-01655A ASS’Y PARTITION ASS’Y, SGCC-M 1 1 S
A
12 DB27-00041A REACTOR PPS,5mH, 10A 1 1 S
A
13 DB96-08373A ASS’Y COND UNIT ASS’Y 1 1 S
A
14 DB63-01996A COVER VALVE PP, SC-90073R 1 1 S
A
15 DB90-02876C ASS’Y CABINET SIDE RH ASS’Y, SC-94445T 1 1 S
A
16 DB90-01713A ASS’Y CABINET SIDE LF ASS’Y, SC-94445T 1 1 S
A
16-1 DB64-00982A CABINET SIDE LF SECC-P, SC-94445T 1 1 S
A
16-2 DB64-00992A HANDLE LF PP 1 1 S
A
17 G4C090LUDER COMPRESSOR ROTARY, BLDC 1 1 S
NA
17-1 DB99-00987A ASST GROMMET NR 3 3 S
NA
17-2 DB60-30028A SCREW HEX M8 3 3 S
NA
17-3 DB60-30018A SCREW MACHINE M5 1 1 S
NA
17-4 DB63-00489A COVER TERMINAL PBT (G/F 15%) 1 1 S
NA
17-5 DB63-00817A GASKET EPDM 1 1 S
NA
18 DB63-01647A FELT COMP SIDE FELT+PVC Sheet 1 1 S
A
19 DB63-01958A FELT COMP BASE FELT+PVC Sheet 1 1 S
A
20 DB63-01710B FELT COMP UPPER FELT+PVC Sheet 1 1 S
A
21 DB96-08389A ASS'Y VALVE 4WAY ASS'Y 1 1 S
A
21-1 DB62-02286A 4WAY VALVE R410A, SANHUA 1 1 S
NA
21-2 DB62-02284A VALVE SERVICE R410A, SANHUA, 3/8" 1 1 S
NA
22 DB96-08390A ASS'Y VALVE EEV ASS'Y 1 1 S
A
22-1 DB62-03964A VALVE EXPANSION COIL FUJIKOKI, Φ1.4 1 1 S
NA
22-2 DB62-03916A VALVE EXPANSION BODY FUJIKOKI, Φ1.4 1 1 S
NA
22-3 DB62-02283A VALVE SERVICE R410A, SANHUA, 1/4" 1 1 S
NA
23
DB93-05534E ASS'Y CONTROL OUT ASS'Y - 1 S
A
DB93-05534F ASS'Y CONTROL OUT ASS'Y 1 - S
A
24 DB64-02028A SCREEN COND BAR P.E.H 100% 1 1 S
A
25 DB32-00176D THERMISTOR OUT/DIS ASS’Y 1 1 S
A
26 DB32-00121B THERMISTOR COND ASS’Y 1 1 S
A
27 DB93-04489A CONNECT WIRE COMP ASS’Y 1 1 S
A
28 DB63-01934A FELT COMP SIDE OUT ASS’Y 1 1 S
A
29 DB63-02034A FELT COMP UPPER OUT ASS’Y 1 1 S
A
