 OUTDOOR PCB : DB93-04263C(AQV12VBCX), DB93-04263D(AQV09VBCX)(cont.)
Electrical Parts List
Samsung Electronics 6-10
C414 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 SNA
C415 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C455 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C471 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C503 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C506 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C507 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C509 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C513 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C514 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C515 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C516 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C517 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C518 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C520 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C522 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C523 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C524 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C525 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C526 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 S
NA
C417 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 S
NA
C419 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 S
NA
C519 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 S
NA
C803 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 S
NA
C201 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 S
NA
C203 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 S
NA
C302 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 S
NA
C305 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 S
NA
C306 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 S
NA
C307 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 S
NA
C521 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 S
NA
C303 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,1608 1 S
NA
C421 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,1608 1 S
NA
C105 2203-000609 C-CER,CHIP 22nF,10%,50V,X7R,TP,2012 1 S
NA
C802 2203-000609 C-CER,CHIP 22nF,10%,50V,X7R,TP,2012 1 S
NA
C452 2203-000888 C-CER,CHIP 4.7nF,10%,50V,X7R,1608 1 S
NA
C906 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 S
NA
C907 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 S
NA
C451 2203-002002 C-CER,CHIP 33pF,5%,50V,NPO,BK,1608,- 1 S
NA
C402 2203-002041 C-CER,CHIP 0.47nF,10%,50V,X7R,1608 1 S
NA
C404 2203-002041 C-CER,CHIP 0.47nF,10%,50V,X7R,1608 1 S
NA
C406 2203-002041 C-CER,CHIP 0.47nF,10%,50V,X7R,1608 1 S
NA
C407 2203-002041 C-CER,CHIP 0.47nF,10%,50V,X7R,1608 1 S
NA
C113 2203-005819 C-CER,CHIP 1000nF,+80-20%,16V,Y5V,-,1608 1 S
NA
C900 2203-006104 C-CER,CHIP 1000nF,10%,50V,X7R,3225 1 S
NA
Location No. Code No. Description Specification Q’ty SA/SNA
