 EMI PCB : DB93-04264A
C001 2201-000540 C-CERAMIC,DISC 4.7nF,20%,2kV,Y5U,BK,12x5mm,10 1 SNA
C002 2201-000540 C-CERAMIC,DISC 4.7nF,20%,2kV,Y5U,BK,12x5mm,10 1 SNA
C003 2301-001285 C-FILM,LEAD-PPF 680nF,10%,275V,BK,31x11x21mm,27.5 1 SNA
C004 2301-001325 C-FILM,LEAD-PPF 330nF,10%,275V,TP,26x8.5x18mm,22.5 1 SNA
C010 2201-000540 C-CERAMIC,DISC 4.7nF,20%,2kV,Y5U,BK,12x5mm,10 1 SNA
C011 2201-000540 C-CERAMIC,DISC 4.7nF,20%,2kV,Y5U,BK,12x5mm,10 1 SNA
DSA 4715-001093 SURGE ABSORBER 3600V,20%,2000A,-,AXIAL 1 SNA
FT00 DB98-17990A ASSY-EMI FILTER SH12BWH,LS615044 1 SNA
FT01 DB98-17990A ASSY-EMI FILTER SH12BWH,LS615044 1 SNA
FUSE 3601-001159 FUSE-CARTRIDGE 250V,20A,SLOW-BLOW,CERAMIC,31.8x6.35mm 1 SNA
FUSECLIP 3602-001038 FUSE-CLIP 250V,30A,10mohm 1 SNA
VA04 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP 1 SNA
VA07 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP 1 SNA
VA08 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP 1 SNA
VA09 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP 1 SNA
- 6042-001009 EYELET ID1.8,OD2.2,L3,-,BRASS 8 SNA
- DB39-00514F CBF LEAD WIRE-EARTH -,KFR-35(25)GW/GPI,-,200,-,-,-,GRN/YEL,-,-,- 1 SNA
- DB39-00961T CBF LEAD WIRE -,SH12BWH,-,120,10A,230V/50Hz,-,BRW,-,-,INVERTER 1 SNA
- DB39-00961U CBF LEAD WIRE -,SH12BWH,-,120,10A,230V/50Hz,-,BLU,-,-,INVERTER 1 SNA
- DB39-00998C CBF LEAD WIRE-POWER -,KFR-35(25)GW,2P,140,-,220V,-,BRN/SKYBLU,-,-, 1 SNA
AC POWER WIRE
- DB41-00532A PCB SUB FORTE,FR-1,1,1.0,1.6T,160x140mm,-,3,-,- 1 SNA
Location No. Code No. Description Specification Q'TY SA/SNA Remark
6-11
Electrical Parts List
