SAMSUNG ELECTRONICS
8. Operating Instructions 65
8-1 Name of Each Part 65
8-2 Wireless Remote Control-Buttons and Display 66
9. Troubleshooting 67
9-1 Items to be checked First
67
9-2 Communication Error 68
10. Block Diagram 86
10-1 Indoor unit 86
10-2 Outdoor unit 87
11. Reference Sheet 90
11-1 Low Refrigerant Pressure Distribution 90
11-2 Pressure & Capacity mark 90
11-3 Q & A for Non-trouble 91
11-4 Cleaning /Filter Change 94
11-5 Installation 99
11-6 Installation Diagram of Indoor Unit and Outdoor Unit 100
11-7 Reference sheet 103
