Samsung AR09TXCAAWKXEU - Page 34

34
SAMSUNG ELECTRONICS
No. Parts Procedure Remark
3 Assy Control Out 1) To remove the Cover control box : Pull
the motor wire is allow sufcient space
as shown on the right side and then
remove the screw.
2) Detach several connectors from the
Assy Control Out.
