SAMSUNG ELECTRONICS
4-4 Outdoor Unit (Q)
AR18TX***WKXEU
AR24TX***WKXEU
No. Parts Procedure Remark
1 Common work 1) Loosen xing screws from the cabi
side Rh and detach it.
2) L oosen each sc rews and detach the
Cabi Top Cover.
3) Loosen xing screws from the cabi
side.
4) Loosen xing screws from the
cabi side Rh and detach it.
