No. Parts Procedure Remark
2 Fan
&
Motor
1) Detach the Nut Flange like the picture
on the right side. (Turn clockwise
because the screw is left-handed.)
(Use Monkey Spanner.)
2) Detach the Fan Propeller.
3) Loosen 4 xing screws to detach the
Motor.
(Use Monkey Spanner.)
4) Disconnect the wire between Assy
Control Out and Motor.
5) Loosen xing bolts and detach the
Bracket Motor
To Next Page
