CN210 : DOWNLOAD CN551 : DOWNLOAD CN470 : SENSOR
#1 RXD #1 RXD #1 OUT-TH
#2 TXD #2 TXD #2 GND
#3 BOOT #3 BOOT #3 DIS-TH
#4 TDO #4 TDO #4 GND
#5 TCK #5 TCK #5 COND-TH
#6 TDI #6 TDI #6 GND
#7 TMS #7 TMS #7 OLP-TH
#8 TRACECLK #8 TRST #8 GND
#9 GND #9 GND
#10 5V #10 5V CN800 : EEPROM
#11 5V #11 5V #1 GND
#12 NULL #12 NULL #2 NULL
#13 NULL #13 NULL #3 5V
#14 TRACE3 #14 NULL #4 CS
#15 NULL #15 NULL #5 SO_MICOM_RX
#16 NULL #16 NULL #6 SI_MICOM_TX
#17 GND #17 GND #7 CLK
#18 TRACE2 #18 DA_CLK
#19 TRACE1 #19 DA_CS CNP031 : 4 WAY
#20 TRACE0 #20 DA_DATA #1 NE_A
#2 NULL
CNP0051, CNP0052 : REACTOR CNP004 : COMM_GND #3 LI_S
#1 REACTOR#1 #1 GND
#2 REACTOR#2 CNP901 : BLDC FAN
CN700 : HEATER #1 DC_LINK
CN320 : COMM #1 12V #2 NULL
#1 5V #2 GND #3 GND
#2 ENABLE #3 HEATER_N #4 5V
#3 INVERSE #4 HEATER_L #5 FAN_PWM
#4 TDX #6 FAN_FG
#5 RXD CN810 : EEV&LED
#6 GND #1 A3 CN380 : DRED
#7 12V #2 A2 #1 DRED1
#3 A1 #2 DRED2
CNP402 : COMP #4 A0 #3 DRED3
#1 W #5 12V #4 GND
#2 V #5 5V
#3 U CNP002 : POWER N
#1 N
CNP001 : POWER L
#1 L
