Samsung AR09TXCAAWKXEU - Page 9

9
SAMSUNG ELECTRONICS
Model AR09TXCAAWKNEU AR12TXCAAWKNEU
Rating Mode Unit Wall-mounted Wall-mounted
Capacity
T1 Cool W 2500 3500
T3 Cool W - -
Heat W 3200 4000
Power Input
T1 Cool W 540 885
T3 Cool W - -
Heat W 675 940
Current
T1 Cool A 2.9 4.1
T3 Cool A - -
Heat A 3.4 4.4
Efciency
EER W/W 4.63 3.95
- -
COP W/ W 4.74 4.26
Platform
IDU - QF2 QF2
ODU - N-SI N-SI
Evap
Main -
Φ7, ( 2R*10S+1R*4S )*660mm,
(H1.3+H1.3), N.G.S, 1by2
Φ7, ( 2R*10S+1R*4S )*660mm,
(H1.3+H1.3), N.G.S, 1by2
Sub -
Φ7, ( 2R*6S+1R*4S )*660mm, (H1.3+H1.3),
N.G.S : (Q-2-3)
Φ7, ( 2R*6S+1R*4S )*660mm, (H1.3+H1.3),
N.G.S : (Q-2-3)
Cond
Main -
Φ7W, 2R*24S*850/825mm, Corrugate1.5,
N.G.S, 4by4by2
Φ7W, 2R*24S*850/825mm, Corrugate1.5,
N.G.S, 4by4by2
Sub - - -
Comp Model - KTN130D42UFR KTN130D42UFR
Motor In
Code - DB31-00636A DB31-00636A
Name - RD-310-25-8A(AL) / SIC-41CVJ-F127-2 RD-310-25-8A(AL) / SIC-41CVJ-F127-2
Motor Out
Code - DB31-00642C DB31-00642C
Name - RD-310-45-8B RD-310-45-8B
Expansion Φ * L - Φ1.3 [029] Φ1.3 [029]
Refrigerant
type - R32 R32
charge g 965 g 965 g
SVC Valve Liquid / Gas - Φ6.35/Φ9.52 Φ6.35/Φ9.52
Tube Dis. / Suc. - Φ9.52/Φ12.7 Φ9.52/Φ12.7
Power Cord - 20*550 20*550
4-WAY V/V - 2 hp 2 hp
Power Supply V/Hz/Φ 220-240/50/1 220-240/50/1
Climate Class - T1 T1
NOISE
IDU UT,T dB 42 / 56 dB↓ 44 / 58 dB↓
ODU dB 51 / 59 dB↓ 53 / 62 dB↓
Net Size
(W*D*H)
IDU
mm
889*299*215 889*299*215
ODU 790*548*285 790*548*285
Weight
IDU
kg
8.9 8.9
ODU 34 34
Operation range
Cooling
IDU 16 ~ 32℃ 16 ~ 32℃
ODU -10 ~ 46℃ -10 ~ 46℃
Heating
IDU 8 ~ 27 °C 8 ~ 27 °C
ODU -15 ~ 24℃ -15 ~ 24℃
