23
SAMSUNG ELECTRONICS
No. Parts Procedure Remark
PANEL-FRONT 5) The GRILLE INLET is xed to body by
hooks in the center and side area.
6) Separate the hook pulling end of the
GRILLE INLET as shown in gures.(Watch
out for the damage of hooks)
7) To detach the PANEL FRONT from the
main frame, unfasten 2 screws at the
bottom. (use (+) Screw Driver)
8) To detach the PANEL FRONT from the
main frame, loosen 4 hook structures.
When separate the hooks: pull out each
ribs near the hooks as shown in gures.
(Watch out for the damage of hooks)
