PCB MAIN : DB92-04838A
CN810
CN5
CNP901
CN470
CN70
CN320
CN210
CN380
CN800
CNP401
CN051CN052
#1 RXD #1 RXD #1 DRED 1 #1 5V #1 OUT_TH
#2 TXD #2 TXD #2 DRED 2 #2 ENABLE #2 GND
#3 BOOT #3 BOOT #3 DRED 3 #3 INVERSE #3 DIS_TH
#4 TDO #4 TDO #4 GND #4 TXD #4 GND
#5 TCK #5 TCK #5 5V #5 RXD #5 COND_TH
#6 TDI #6 TDI #6 GND #6 GND
#7 TMS #7 TMS #7 12V #7 OLP_TH
#8 NTRST #8 TRACECLK #1 GND #8 GND
#9 GND1 #9 GND1 #2 NULL
#10 5VDC #10 5VDC #3 5VDC #1 U
#11 5VDC #11 5VDC #4 CS #2 V #1 310VDC
#12 NULL #12 NULL #5 RX #3 W #2 NULL
#13 NULL #13 NULL #6 TX #3 GND
#14 NULL #14 TRACE3 #7 CLK #4 15VDC
#15 NULL #15 NULL #1 REACTOR#1 #5 Rx
#1
6 NULL #16 NULL #1 REACTOR#2 #6 FG
#17 GND1 #17 BOOT #1 ORG
#18 CLK #18 TRACE2 #2 RED
#19 CS #19 TRACE1 #3 YEL #1 12VDC
#20 Tx #20 TRACE0 #4 BLK #2 GND
#5 GRY #3 N
#4 L
