33
SAMSUNG ELECTRONICS
No. Parts Procedure Remark
10) Please allign the wire such as
picture if you re-assemble after separate
connector wire
.
If the connector is excessively folded,
there is a risk of re.
11) Please remove the CABINET SIDE
upward direction.
2 FAN&MOTOR 1) Please Loosen the NUT 1ea clockwise.
(Using MONKEY SPANNER)
2) Please remove the HOUSING’s MOTOR
WIRE.
3) Remove the xing points of the
motor SCREW 2ea, please disconnect the
MOTOR turning counterclockwise.
To Next Page
