46
SAMSUNG ELECTRONICS
No. Parts Procedure Remark
3 Assy
Control Out
1) To remove the Cover control box : Pull
the motor wire is allow sufcient space
as shown on the right side and then
remove the screw.
2) Detach several connectors from the
Assy Control Out.
3) Detach several connectors from the
PCB of Assy Control Out.
4 Heat Exchanger 1) Release the refrigerant at rst.
2) Loosen ng screw on both sides.
3) Disassemble the pipes in both
inlet and outlet with welding torch.
4) Detach the Heat Exchanger.
To Next Page
