Samsung AR18TXEAAWKXEU - Page 8

8
SAMSUNG ELECTRONICS
Model AR12TXEAAWK/EU AR18TXEAAWKNEU AR18TXFCAWKNEU AR24TXFCAWKNEU
Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted Wall-mounted
Capacity
T1 Cool W 3500 5000 5000 6500
T3 Cool W - - - -
Heat W 4000 6000 6000 7400
Power Input
T1 Cool W 930 1390 1390 1950
T3 Cool W - - - -
Heat W 1070 1610 1700 2350
Current
T1 Cool A 6.8 6.4 6.4 8.8
T3 Cool A - - - -
Heat A - 7. 5 7.8 10.5
Efciency
EER W/W 4.50 3.60 3.60 3.33
- - - -
COP W/ W 5.10 3.73 3.51 3.15
Platform
IDU - QF2 QF3 QF3 QF3 (AIRISE)
ODU - N-SI Q-480 Q-480 Q-480
Evap
Main - Φ7, 2R*10S*660mm, H1.3, N.G.S, 2by2
Φ7, ( 2R*10S+1R*4S )*825.5mm,
(H1.3+H1.3), N.G.S, 4by4
Φ7, 2R*10S*825.5mm, H1.3, N.G.S, 4by4 Φ7, 2R*10S*825.5mm, H1.3, N.G.S, 4by4
Sub - Φ7, 2R*5(6)S*660mm, H1.3, N.G.S : (Q-2-1)
Φ7, ( 2R*6S+1R*4S )*825.5mm,
(H1.3+H1.3), N.G.S : (Q-3-6)
Φ7, 2R*5(6)S*825.5mm, H1.3, N.G.S : (Q-3-
3)
Φ7, 2R*5(6)S*825.5mm, H1.3, N.G.S : (Q-3-
4)
Cond
Main -
Φ7W, 2R*24S*850/825mm, Corrugate1.5,
N.G.S, 4by4by2
Φ7W, 2R*28S*906.8mm, Corrugate1.5,
N.G.S, 4by4by1
Φ7W, 2R*28S*906.8mm, Corrugate1.5,
N.G.S, 4by4by1
Φ7W, 2R*28S*906.8mm, Corrugate1.5,
N.G.S, 4by4by1
Sub - - - - -
Comp Model - UB1AR5090FE6 UB9TK3150FE4 UB9TK3150FE4 UB9TK2150FE4
Motor In
Code - DB31-00636A DB31-00637A DB31-00636A DB31-00636A
Name - RD-310-25-8A(AL) / SIC-41CVJ-F127-2 RD-310-25-8B / SIC-37CVL-F127-2 RD-310-25-8A(AL) / SIC-41CVJ-F127-2 RD-310-25-8A(AL) / SIC-41CVJ-F127-2
Motor Out
Code - DB31-00642C DB31-00642C DB31-00642C DB31-00658D
Name - - - - -
Expansion Φ * L - EEV 1.3 Φ1.4 Φ1.4 Φ1.4
Refrigerant
type - R32 R32 R32 R32
charge g 940 g 1300 g 1300 g 1150 g
SVC Valve Liquid / Gas - 6.35/9.52 Φ6.35/Φ12.7 Φ6.35/Φ12.7 Φ6.35/Φ15.88
Tube Dis. / Suc. - 7.94/9.52 Φ9.52/Φ12.7 Φ9.52/Φ12.7 Φ9.52/Φ12.7
Power Cord - 20*550 20*550 20*550 20*550
4-WAY V/V - 1 hp 2 hp 2 hp 2 hp
Power Supply V/Hz/Φ 220-240/50/1 220-240/50/1 220-240/50/1 220-240/50/1
Climate Class - T1 T1 T1 T1
NOISE
IDU UT,T dB 43 / 57 48/58 dB↓ 48/58 dB↓ 51 / 62 dB↓
ODU dB 53 / 62 57 / 65 dB↓ 57 / 65 dB↓ 60 / 68 dB↓
Net Size
(W*D*H)
IDU
mm
889*299*215 1055*299*215 1055*299*215 1055*299*215
ODU 950*290*375 880*638*310 880*638*310 880*638*310
Weight
IDU
kg
10.6 12.5 12.5 12.5
ODU 12.7 43.7 43.7 43.7
Operation range
Cooling
IDU 16 ˚C~32 ˚C 16 ~ 32℃ 16 ~ 32℃ 16 ~ 32℃
ODU -10 °C to 46 °C -10 ~ 46℃ -10 ~ 46℃ -10 ~ 46℃
Heating
IDU 8 ~ 27 °C 8 ~ 27 °C 8 ~ 27 °C 8 ~ 27 °C
ODU -15 °C to 24 °C -15 ~ 24℃ -15 ~ 24℃ -15 ~ 24℃
