Samsung Electronics14

4-2 Outdoor Unit

No Parts Procedure Remark

1 Common Work

1) Loosen 1 fixing screw of the Cover-Side.

2) Loosen each 3 fixing screws on both right

and left Cabinet-Side edge and a fixing

screw on the Cabinet-Front lower to detach

the Cabinet-Front.

3) Loosen 6 fixing screws of the Cabinet-Side

RH.

4) Loosen 2 fixing screws of the Cabinet-Side

LF.

DB98_20801A(1)_1 12/24/04 10:46 AM Page 14

Other manuals for Samsung AS12HPBN

Need help?

Do you have a question about the Samsung AS12HPBN and is the answer not in the manual?

General

Cooling Capacity	12000 BTU/h
Heating Capacity	13000 BTU/h
Refrigerant	R410A
Power Supply	220-240V, 50Hz
Energy Efficiency Ratio (EER)	3.21
Power Consumption (Cooling)	1120 W
Noise Level (Indoor)	38 dB(A)
Net Weight (Indoor Unit)	9 kg
EER	3.21 W/W
COP	3.61 W/W
Operating Temperature (Cooling)	18°C to 43°C
