Air Conditioning Unit - Main Parts and Control Panel
Air filter(The air filter
is located in inside.)
Ventilation lever
Power plug
(The type of power plug
may differ, depending on
the local power supply.)
Air outlet
Outer air flow blades
(up/down orientation)
Inner air flow blades
(right/left orientation)
Air inlet (Outside)
Temperature control dial
Timer control dial
Air flow blade swing switchFan speed switch
Air inlet(Inside)
❄ The design and shape are subject to
change according to the model.
