Installing the Oven (Continued)
Installing into a high cabinet
● Observe minimum clearance requirements.
● The oven should be slid into place at the proper angle of alignment.
1
560
551
595
34.6
594.5
538.5
2
min.550
min.590~max.600
min.560
50
3 4
Live Earth
Neutral
5
Connecting the oven to the power supply
(H05VV-F, H05RR-F, Min 1.6m, 2.5mm²)
