7-3 Samsung Electronics
7-2 Main Parts List - CE2713T (WHITE/BLUE/BROWN)
Exploded Views and Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks
M 1 DE70-30116W PANEL-OUTER;SECC,T0.5,W351.7,L10;STS430,T0.5,W70,L70,-,3RD-W 1 WHITE
M 1 DE70-30135S PANEL-OUTER;SECC,T0.5,W351.7,L1014.7,BLUE,3RD,M1774B/XEU 1 BLUE
M 1 DE70-30135J PANEL-OUTER;SECC,T0.5,W351.7,L1014.7,BRN,- 1 BROWN
M 2 DE63-90035G CUSHION-RUBBER;DFA20,T2,W190,L100,BLK 1
M 3 DE61-50323A BRACKET-UPPER;SECC,T0.6,W385,L205,M6245G 1
M 4 DE61-30008A SUPPORTER-HEATER;ALUMINA,T12,CE745G 1
M 5 DE61-70060A SPRING-PLATE;SK-5,T0.5 1
M 6 DE47-00004A HEATER-GRILL;SHG-2733E,-,-,-,-,-,-,-,230V1080W 1
M 7 DE60-40009B WASHER-TEFLON;SLOT,ID22.2,OD28,T1.2,TEFLON 1
M 8 DE63-20017A GASKET-HEATER;BRASS,T1.5,OD30.5,ID22.5 1
M 9 DE61-50576A BRACKET-HEATER;STS430,T0.5,W70,L70,-,3RD-W 1
M10 DE74-80062A STOPPER-HEATER;SECC,T0.8xW70xL70,-,-,-,3RD-W 1
M11 DE39-20058L ASSY POWER CORD;230V50HZ,-,GRY,CE2713/XEF,1.5SQ 1
M12 DE65-20014A CABLE CLAMP;DA-6N,NY-66 1 P-CORD
M13 DE39-40409A WIRE HARNESS-E;230V50HZ,M9G45,CTW 1 H/EART
M14 DE71-60451A COVER-BACK;SECC,T0.5,W115,L332,-,3RD-0.7, 1
M15 DE39-00037A WIRE HARNESS-A;230V50HZ,-,-,CE2713(INRUSH),AMFO 1
M16 DE96-00008A ASSY NOISE FILTER;SN-3WEB,250V10A,3W INRUSH D 1
M17 DE71-60467A COVER-BLOWER;PP,-,-,-,-,3RD-0.7 1
M18 DE96-00031A ASSY MOTOR-FAN;SMF-3RDEA,230V50HZ,2400RPM,M1733 1
M19 4713-001031 LAMP-INCANDESCENT;230V,173mA,40W,ORG,-,-,25x69mm 1 CV/AIR
M20 DE47-20009A THERMOSTAT;PW2N-520PB,160/60,250V/7.5A,H, 1 MG-TCO
M21 DE03-30035A MAGNETRON;OM75PH((31)ESS 1
M22 DE71-60457A COVER-AIR;PP,T1.7,W115.5,L150,WHT,3RD-W0 1
M23 DE93-20101A ASSY BODY LATCH;3RD-0.7,P/BUTTON,PP 1
M24 DE66-90113A LEVER-DOOR;PP(TB53-GH10),T2.5,W31X100.5,-,12G,NTR,3RD-W 1
M25 DE71-60462A COVER-CEILING;MICA-SHEET,T0.3,W109.2,L114.2, 1
M26 DE47-20010A THERMOSTAT;PW-2N(120/60)187Y,250V7.5A,120 1 CAV-TCO
M27 DE31-10154A MOTOR-DRIVE;M2HJ49ZR02,ST-16,50/60HZ,- 1
M28 DE80-10003D BASE-PLATE;SGCC1-Z,T0.8,-,-,CE2713/33/CE2714/74,3RD-W 1
M29 DE26-00010A TRANS-H.V;SHV-273EG,230V50HZ,2215V/3.40V,-,KE 1
M30 2501-001015 C-OIL;1.0uF,2100V,BK,35X54X80,20mm 1
M31 DE61-50106A BRACKET-HVC;SECC,T0.8,W31,L125.8 1
M32 DE61-40017A FOOT;PP(A353),BLK,MW5630T 2
M33 DE59-00002A DIODE-H.V;ESJC13-12B,12KV,-,-,-,MWO ALL,-,RING&FLAT TERMINAL 1
M34 DE91-70061B ASSY-H.V.FUSE;THV060T-0750-H,5KV0.75A,RED 1
M35 DE94-00089B ASSY DOOR;CE2733,WHT 1 WHITE
M35 DE94-00089H ASSY DOOR;CE2713B/XEG,BLUE,3RD-0.7CU.FT(S2) 1 BLUE
M35 DE94-00089J ASSY DOOR;CE2713M/XEG,D/BRN,3RD-0.7CU.FT(S2) 1 BROWN
M36 DE94-00132L ASSY CONTROL-BOX;230V50HZ,CE2713T/XEG,P/WHT 1 WHITE
M36 DE94-00132M ASSY CONTROL-BOX;230V50HZ,CE2713T-B/XEG,BLUE 1 BLUE
M36 DE94-00132N ASSY CONTROL-BOX;230V50HZ,CE2713T-M/XEG,D/BRN 1 BROWN
M37 DE74-20102B TRAY-COOKING;GLASS,T5.0,PI288,780G,M745 1
M38 DE92-90436C ASSY-GUIDE ROLLER;MW4370W,D16.5,XAREX 1
M39 DE67-60075A COUPLER;PPS,7G,BRN,M97G45 1
M40 DE74-70071B RACK-WIRE;MSWR3,PI3,PI230,HI80,SNC2 1
M40 DE97-00106A ASSY-WIRE RACK;CURSTY-TRAY 1 TRAY ONLY
M41 DE47-20032A THERMOSTAT;PW-2N,85/75 1 GRL-TCO
M42 DE63-00004A CUSHION-HVT;EPDM,T2,W30,L50,-,BLK,CE2733 1
M43 DE27-10020A COIL-MC CHOKE;TC,101 1
M44 3601-000448 FUSE-FERRULE;250V,10A,SLOW-BLOW,CERAMIC,6.3 1
M45 3601-001126 FUSE-FERRULE;250V,1.6A,QUICK-ACTING,CERAMIC 1
M46 DE74-20114A TRAY-BROILER;AL,T0.8,265,22.5,265,TEFRON CO 1 TRAY ONLY
: Option Parts
: Warning
:Electrostatically Sensitive Devices
