Samsung CE2713 - Standard Parts List

Samsung Electronics7-5
Parts No. Description / Specification Q'ty Remarks
DE60-10012A SCREW-TAP TITE;TH,+,3,M4,L10,SWR10,ZPC2,TOOTH 1 P-CORD
DE60-10018A SCREW-ASSY MACHINE;PH,M4X0.7P,8,MSWR10,SN1,WS 2 BKT-HEATER
DE60-10045A SCREW-TAP PH;PH,M3,L6,FEFZY 1 GRL-TCO
DE60-10080A SCREW-WASHER;M5,L12,2S 4 HVT
DE60-10080A SCREW-WASHER;M5,L12,2S 4 MGT
DE60-10082H SCREW-A;2S-4X12,TOOTHED 2 B-LATCH
DE60-10082H SCREW-A;2S-4X12,TOOTHED 3 B-PLATE
DE60-10082H SCREW-A;2S-4X12,TOOTHED 3 BKT-UPPER
DE60-10082H SCREW-A;2S-4X12,TOOTHED 2 C-BACK
DE60-10082H SCREW-A;2S-4X12,TOOTHED 1 C-BLOWER
DE60-10082H SCREW-A;2S-4X12,TOOTHED 1 C-CLAMP
DE60-10082H SCREW-A;2S-4X12,TOOTHED 1 CON-BOX
DE60-10082H SCREW-A;2S-4X12,TOOTHED 1 COVER-AIR
DE60-10082H SCREW-A;2S-4X12,TOOTHED 4 OUT-PANEL
DE60-10098A SCREW-ASSY TAP TITE;PH,TC,M4X8,SWRCH18A,ZPC2,GLD,W 1 CVT-TCO
DE60-10098A SCREW-ASSY TAP TITE;PH,TC,M4X8,SWRCH18A,ZPC2,GLD,W 2 D-MOTOR
DE60-10098A SCREW-ASSY TAP TITE;PH,TC,M4X8,SWRCH18A,ZPC2,GLD,W 2 MGT-TCO
DE60-10122A SCREW-TAP TH;TAP,TH,2-4X8,FE,FN 1 CV-CEILING
DE60-10122A SCREW-TAP TH;TAP,TH,2-4X8,FE,FN 1 P-OUTER
DE60-20063A BOLT-FLANGE;M4,10,ZPC3,YEL,MSWR 2 H/LOWER
DE60-20063A BOLT-FLANGE;M4,10,ZPC3,YEL,MSWR 2 H/UPPER
DE60-30016A NUT-FLANGE;M4,MSWR10,-,-,-,-,-,-,-;PH,TC,M4X8,SWRCH18A,ZPC2,GLD,W 1 -
DE60-10012A SCREW-TAP TITE;TH,+,3,M4,L10,SWR10,ZPC2,TOOTH 1 -
DE60-10069A SCREW-TAP TH;TH,M4,L10,FRFZY 1 RELAY
DE60-10072A SCREW-TAP TH;TH,M4,L16,FEFZY,2-SLOT 4 TIMER
7-6 Standard Parts List
Exploded Views and Parts List
