7-4Samsung Electronics
7-3 Door Parts List - CE2713/CE2713T (WHITE/BLUE/BROWN)
Ref. No. Parts No. Description/Specification Q'ty Remarks
D 1 DE64-40322C DOOR-A;ABS,-,-,-,-,CE2733/XEF,TDS GRILL 1 WHITE
D 1 DE64-40322K DOOR-A;ABS,-,-,-,BLUE,CE2713B/XEG,GRILL 1 BLUE
D 1 DE64-40322J DOOR-A;ABS,-,-,200G,BRN,CE2713M/XEG,3RD-S2 1 BROWN
D 2 DE67-20186A SCREEN-DOOR;SAN,T2.2,W354,L224,SMOG,3RD-0.7CU.FT 1
D 3 DE92-50126B ASSY DOOR-E;COATING,BLK,CE745G 1 WHITE
D 3 DE92-50133F ASSY DOOR-E;CE2733(3RD-0.7),BLK-CAOTING,-,2ND-HINGE 1 BLUE/BROWN
D 4 DE64-40008B DOOR-C;PP,T1.5,BLK,CE745G 1
D 5 DE64-40006F DOOR-KEY;POM(F20-02),-,-,12G,BLK,MW7897G,NO-TALK 1
D 6 DE01-00003B FILM-DOOR;PC,T0.2,W142,L260.5,TRP,CE745G 1 WHITE
D 6 DE01-00112B FILM-DOOR;PET,T0.15,W150,L268,NTR,3RD-GRILL 1 BLUE
D 6 DE01-00112A FILM-DOOR;PET,T0.15,W150,L268,NTR,3RD-W 1 BROWN
D 7 DE61-70033A SPRING-KEY;ES,HSWR10,PI0.6,D6.0,L22.3,BLU 1
D 8 DE61-80005A HINGE-UPPER;SCP1,T2.3,ZN-COATIN,M745 1
D 9 DE61-80004A HINGE-LOWER;SCP1,T2.3,ZN-COATING,M745 1
7-4 Control Parts List - CE2713/CE2713T (WHITE/BLUE/BROWN)
Ref. No. Parts No. Description/Specification Q'ty Remarks
C 1 DE66-20281A BUTTON-PUSH;ABS,15g,T2x37x86,WHT,3RD-W B D 1 WHITE (CE2713/CE2713T)
C 1 DE66-20281C BUTTON-PUSH;ABS,-,15G,BLU,M1713-V/XEF 1 BLUE (CE2713/CE2713T)
C 1 DE66-20281B BUTTON-PUSH;BRN,M1713-M,SRD-S2 1 BROWN (CE2713/CE2713T)
C 2 DE61-70076A SPRING-BUTTON;HSWR,PI0.6 1
C 3 DE64-10162A KNOB;ABS,-,WHT,-,3RD-W 2 WHITE (CE2713/CE2713T)
C 3 DE64-10162C KNOB;ABS,-,BLUE,-,M1713-B/XEG 2 BLUE (CE2713/CE2713T)
C 3 DE64-10162B KNOB;ABS,-,BRN,-,M1713-M 2 BROWN (CE2713/CE2713T)
C 4 DE72-70214B CONTROL-PANEL;CE2713,-,-,-,-,WHT 1 WHITE (CE2713)
C 4 DE72-70214L CONTROL-PANEL-D;ABS,CE2713T/XEG,-,-,-,-,P/WHT 1 WHITE (CE2713T)
C 4 DE72-70214F CONTROL-PANEL-D;ABS,CE2713B/XEG,-,-,-,-,BLUE 1 BLUE (CE2713)
C 4 DE72-70214M CONTROL-PANEL-D;ABS,CE2713T-B/XEG,-,-,-,-,BLUE 1 BLUE (CE2713T)
C 4 DE72-70214G CONTROL-PANEL-D;ABS,CE2713M/XEG,-,-,-,-,BRN 1 BROWN (CE2713)
C 4 DE72-70214N CONTROL-PANEL-D;ABS,CE2713T-M/XEG,-,-,-,-,D/BRN 1 BROWN (CE2713T)
C 5 3501-000309 RELAY-POWER;240V,3750VA,15A,-,6mS,20mS 1
C 6 DE45-00003A TIMER;TMFK60M1A1,-,-,-,-,-,-,310 GRILL 1
C 7 DE94-00128B ASSY CONTROL-PANEL;AC230V50HZ,CE2713,WHT 1 WHITE (CE2713)
C 7 DE94-00128L ASSY CONTROL-PANEL;230V50HZ,CE2713T/XEG,P/WHT 1 WHITE (CE2713T)
C 7 DE94-00128F ASSY CONTROL-PANEL;230V50HZ,CE2713-B/XEG,BLUE,3RD-S2 1 BLUE (CE2713)
C 7 DE94-00128M ASSY CONTROL-PANEL;230V50HZ,CE2713T-B/XEG,BLUE 1 BLUE (CE2713T)
C 7 DE94-00128G ASSY CONTROL-PANEL;230V50HZ,CE2713-M/XEG,D/BRN,3RD-S2 1 BROWN (CE2713)
C 7 DE94-00128N ASSY CONTROL-PANEL;230V50HZ,CE2713T-M/XEG,D/BRN 1 BROWN (CE2713T)
7-5 Body Latch Parts List - CE2713/CE2713T (WHITE/BLUE/BROWN)
Ref. No. Parts No. Description/Specification Q'ty Remarks
B 1 DE66-40001C LATCH-BODY;PP(FB53WH),-,39.2G,NTR,-,3RD-W MW5592W 1
B 2 3405-000178 SWITCH-MICRO;250V,15A,200gf,SPST-NO 2
B 3 3405-000175 SWITCH-MICRO;250V,15A,200gf,SPST-NO 1
B 4 DE66-90114A LEVER-S/W;PP(FB53WH),-,-,-,3.5G,NTR,3RD-W MW5592W 1
Exploded Views and Parts List
