Samsung CE957GR - Door Parts List; Control Parts List

Samsung Electronics 7-3
7-2 Door Parts List
Ref. No. Parts No. Description Specification Q'ty Remarks
D 1 DE64-40274A DOOR-A ABS,T3,W284,L411,350G,WHT,M957 1
D 2 DE64-40280D DOOR-SCREEN P.C,T2.0,W252.5,L392.6,NO-VITA 1
D 3 DE64-40275A DOOR-SUB ABS,T2.5,W261,L398.7,300G,WHT, 1
D 4 DE92-50127H ASSY DOOR-E COATING,BLACK,T0.8,-,-,-,- 1
D 5 DE64-40012A DOOR-C RESIN-PP(TB53),T2.0,CE945GF,BL 1
D 6 DE01-00002A FILM-DOOR PET,T0.15,275,175,NTR,CE945GF, 1
D 7 DE64-40264C DOOR-KEY POM(F20-02),5g,BLK,-,2ND HANDL 1
D 8 DE61-70126A SPRING-KEY 0.8,0,36,6,BLUING,-,- 1
D 9 DE61-80002A HINGE-UPPER SCP1,T2.3,26,77,ZPC3,WHT,CE945 1
D10 DE61-80003A HINGE-LOWER SCP1,T2.3,26,77,ZPC3,WHT,CE945 1
7-3 Control Parts List
Ref. No. Parts No. Description Specification Q'ty Remarks
C 1 RC-957G-04 ASSY PCB PARTS MWO,CE957GR,230V50HZ 1
C 2 DE72-70182P CONTROL-PANEL ABS,-,-,-,WHT,170G,CE957GR/BWT 1
C 3 DE67-40147A WINDOW-DISPLAY ACRYL,SMOG,M757/CE757G 1
C 4 DE66-20183B BUTTON-SELECT-B ABS(HR-0370D),WHT,M757(SDW/SKW 1
C 5 DE66-20185A BUTTON-SELECT-A ABS,WHT,M757/CE757G 2
C 6 DE66-20184A BUTTON-SELECT-C ABS(HR-0370D),WHT,M757(SKW,SDW 1
C 7 DE64-10128A KNOB ABS(HR-0370D),WHT,M757/CE757G 1
7-4 Body Latch Parts List
Ref. No. Parts No. Description Specification Q'ty Remarks
B 1 DE66-40001A LATCH-BODY POM(F20-02) 40GR NTR 1
B 2 3405-000178 SWITCH-MICRO VP-533A-OF-PS(T85) 250V,15A 2
B 3 3405-000175 SWITCH-MICRO VP-531A-OF(T85) 250V,15A,20 1
B 4 DE66-90001A LEVER-SWITCH P.O.M(F20-02) 2 6 NTR 2ND-W 1
B 5 DE72-60106A GUIDE-S/W ABS BLK 1
Exploded Views and Parts List
