4.AlignmentandTroubleshooting
4.2.3.Imagequalityproblems
1)VerticalBlackLineandBand
•Description:Straightthinblackverticallineoccursintheprintedimage.
CauseandCheckPointSolution
Checkifthesurfaceofthechargerollerisscratchedor
contaminated.
Replacethetonercartridgeandtestagain.
Checkiftherearegroovesonthecircumferenceofthe
OPCdrum.
Replacethetonercartridgeandtestagain.
CheckifthecleaningbladeisdamagedReplacethetonercartridgeandtestagain.
Checkifpapertransferbeltisdamagedorcontaminated.ReplacetheITBunitandtestagain.
2)VerticalWhiteLine
•Description:Whiteverticalvoidsintheimage.
CauseandCheckPointSolution
CheckiftheLSUwindoworinternallensesofLSUis
contaminated.
CleantheLSUwindowwithrecommendedcleaner(IPA).
Cleanthewindowwithacleancottonswab.Ifdirtis
insidetheLSU,replacetheLSU.
Checkiftherearescratchesonthecircumferenceofthe
OPCdrum.
Replacethetonercartridgeandtestagain.
Checkiftherearescratchesonthecircumferenceofthe
developingroller.
Replacethetonercartridgeandtestagain.
Checkifpapertransferbeltisdamagedorcontaminated.ReplacetheITBunitandtestagain.
